USB 3.1 90° Type C-C Active Optical Cable Backward Compatible

USB 3.1 90° Type C-C Active Optical Cable Backward Compatible

Name: USB 3.1 90° Type C-C Active Optical Cable Backward Compatible
Brand: Elike

Model Number : SCRA-3120

The Elike SCRA-3120 combines a 90-degree USB Type-C connector with USB 3.1 Gen 2 performance and backward compatibility for mixed-generation systems. It transmits SuperSpeed data at up to 10Gbps over a hybrid fiber-and-copper cable and supports USB 2.0 and USB 1.1 devices when the connected host and peripheral use those modes. The right-angle connector reduces projection and bending stress at cameras, VR equipment, wearables, displays and compact computers, while the optical data path helps maintain signal stability in electrically noisy installations. With a cable OD below 4.5 mm, no external power requirement, hot-plug support and up to 5V/1.5A available to the remote device, it is designed for cleaner routing and easier deployment. Lengths from 0.2 to 15 meters can be tailored for the installation, subject to final engineering confirmation.

USB 3.1 90° Type C-C Active Optical Cable backward compatible

USB 3.1 90° Type C-C Active Optical Cable backward compatible 1

USB 3.1 90° Type C-C Active Optical Cable backward compatible 2

Lightweight Active Optical Cable for VR and AR Applications

key Features

Meets USB 3.1 Gen2 Standard with a bandwidth of up to 10Gbps super speed.
Delivers uncompressed signal and distortion-free image quality.
Utilizes a hybrid copper and fiber cable, providing anti-interference, no radiation, and strong EMI resistance.
Equipped with a standard USB Type C interface.
Utilizes 850nm VCSEL and PIN photodetector for reliable performance.
Plug and play functionality with hot-plug support.
Thin cable with OD less than Φ4.5 mm for lightweight applications.
No external power supply required.
Supports a maximum of 5V 1.5A power to the remote device.
Applicable length ranging from 0.2 to 15 meters, with support for other distance customizations.

Applications

AR/VR Devices – High speed connection for AR glasses and VR headsets.
Industrial Cameras – Long distance data transmission for machine vision systems.
Automation Equipment – Suitable for robots, sensors, and inspection systems.
USB-C Extension – Extends USB-C connections up to 30 meters.
Imaging Systems – Supports uncompressed image data transmission.
Space Limited Installations – 90° connector saves space and reduces cable bending.
Interactive Displays – Suitable for digital signage and multimedia equipment.

Specifications

Parameter	Specification
Product Type	USB Type-C Active Optical Cable
Supply Voltage	4.8–5.3 V DC
Rated Supply Current	3 A
Operating Current	45–120 mA
Power Consumption	0.35 W
Operating Temperature	−20°C to 50°C
Storage Temperature	−40°C to 80°C
−40°C to 80°C	4.5 mm typical (4.3–4.7 mm)
